ISDNET, INC.

NETROUTER 1040

Card Type

ISDN to Ethernet router

Chipset

Unidentified

Network Transfer Rate

10Mbps x 4

Topology

Star

Wire Type

Unshielded twisted pair

Error Correction/Compression

STAC

ISDN Transfer Rate

56Kbps x 2/64Kbps x 2

ISDN Protocol

PPP

Switch Type

5ESS, DMS100, NI-1

Data Bus

Serial

CONNECTIONS

Function

Label

Function

Label

AC power in

CN1

UTP connector 2

CN5

Serial port

CN2

UTP connector 3

CN6

ISDN U interface

CN3

UTP connector 4

CN7

UTP connector 1

CN4

Power switch

SW1
