SONY CORPORATION
CDU-541
Device Type |
CD-ROM |
Interface |
SCSI |
Spin Rate |
2x |
Formats Supported |
Audio combined, CD-Audio, CD-ROM (mode 1 & 2), High Sierra, ISO-9660, Red & Yellow Book |
View |
Bottom |
CONNECTIONS | |
Function |
Label |
Audio line out |
CN1 |
USER CONFIGURABLE SETTINGS | |||
Setting |
Label |
Position | |
» |
Parity enabled |
JP1/1 |
Closed |
Parity disabled |
JP1/1 |
Open |
DRIVE SELECT ID | ||||
Drive ID |
JP1/2 |
JP1/3 |
JP1/4 | |
» |
0 |
Open |
Open |
Open |
1 |
Closed |
Open |
Open | |
2 |
Open |
Closed |
Open | |
3 |
Closed |
Closed |
Open | |
4 |
Open |
Open |
Closed | |
5 |
Closed |
Open |
Closed | |
6 |
Closed |
Open |
Open | |
7 |
Closed |
Closed |
Closed |
