FUNAI ELECTRIC CO., LTD.

E2650

Device Type

CD-ROM

Interface

ATAPI

Spin Rate

6x

Formats Supported

Unidentified

View

Top

CONNECTIONS

Function

Label

Audio line out

CN1

ATAPI MASTER/SLAVE

Setting

JP1/1

JP1/2

JP1/3

Single drive only

Open

Open

Closed

Master in two drive system

Open

Open

Closed

Slave in two drive system

Open

Closed

Open

Cable Select

Closed

Open

Open
