QUALOGY, INC.
QPC-5142
|
Processor |
80386DX |
|
Processor Speed |
16/20MHz |
|
Chip Set |
G2 |
|
Max. Onboard DRAM |
8MB |
|
Cache |
None |
|
BIOS |
AMI |
|
Dimensions |
330mm x 120mm |
|
I/O Options |
Parallel port, serial ports (2-RS232, 1-RS422) |
|
NPU Options |
80387DX |
|
CONNECTIONS |
|||
|
Purpose |
Location |
Purpose |
Location |
|
Reset switch |
J1 |
Serial port B (RS232) |
J6 |
|
Speaker |
J2 |
Serial port A (RS232) |
J7 |
|
Keylock |
J3 |
Keyboard |
J8 |
|
Turbo LED |
J4 |
Parallel port |
J9 |
|
Serial port B (RS422) |
J5 |
|
|
|
USER CONFIGURABLE SETTINGS |
|||
|
Function |
Jumper |
Position |
|
|
» |
BIOS type select 27256 |
W1 |
pins 1 & 2 closed |
|
|
BIOS type select 27512 |
W1 |
pins 2 & 3 closed |
|
» |
Monitor type select color |
W2 |
Closed |
|
|
Monitor type select monochrome |
W2 |
Open |
|
» |
RS232 12V from backplane |
W3 |
pins 2 & 3 closed |
|
|
RS232 12V from card |
W3 |
pins 1 & 2 closed |
|
» |
Factory configured - do not alter |
X1 |
Unknown |
|
DRAM CONFIGURATION |
||
|
Size |
Bank 0 |
Bank 1 |
|
1MB |
(4) 256K x 9 |
NONE |
|
2MB |
(4) 256K x 9 |
(4) 256K x 9 |
|
4MB |
(4) 1M x 9 |
NONE |
|
8MB |
(4) 1M x 9 |
(4) 1M x9 |
|
SERIAL PORT CONFIGURATION |
||||||||
|
RS422 (J5) |
RS232 (J6) |
RS232 (J7) |
W8 |
W11 |
W12 |
W13 |
W15 |
W16 |
|
Disabled |
COM2 |
COM1 |
Closed |
pins 1&2 |
Closed |
Closed |
Closed |
pins 1&2 |
|
COM2 |
Disabled |
COM1 |
Open |
pins 2&3 |
Closed |
Closed |
Closed |
pins 1&2 |
|
Disabled |
COM1 |
COM2 |
Closed |
pins 1&2 |
Open |
Closed |
Closed |
pins 2&3 |
|
COM1 |
Disabled |
COM2 |
Open |
pins 1&2 |
Open |
Closed |
Closed |
pins 2&3 |
|
Disabled |
COM2 |
Disabled |
Closed |
pins 1&2 |
Closed |
Closed |
Open |
pins 1&2 |
|
COM2 |
Disabled |
Disabled |
Open |
pins 2&3 |
Closed |
Closed |
Open |
pins 1&2 |
|
Disabled |
COM1 |
Disabled |
Closed |
pins 1&2 |
Open |
Closed |
Open |
pins 2&3 |
|
COM1 |
Disabled |
Disabled |
Open |
pins 1&2 |
Open |
Closed |
Open |
pins 2&3 |
|
Disabled |
Disabled |
COM1 |
N/A |
pins 1&2 |
Open |
Open |
Closed |
pins 1&2 |
|
Disabled |
Disabled |
COM2 |
N/A |
pins 2&3 |
Open |
Open |
Closed |
pins 2&3 |
|
Disabled |
Disabled |
Disabled |
N/A |
N/A |
N/A |
Open |
Open |
N/A |
|
Note: Serial port B is configurable as either a RS422 port using J5 or a RS232 port using J6, but both connectors (J5 & J6) cannot be active at the same time. Pins designated should be in the closed position. |
||||||||
|
SERIAL PORT B (J5/RS422) DRIVER ENABLE CONFIGURATION |
|||
|
Function |
Jumper |
Position |
|
|
» |
DTR signal reflects true state of device |
W4 |
Open |
|
|
DTR signal is forced true |
W4 |
Closed |
|
» |
RTS signal reflects true state of device |
W5 |
Open |
|
|
RTS signal is forced true |
W5 |
Closed |
|
» |
CTS signal reflects true state of device |
W6 |
Open |
|
|
CTS signal is forced true |
W6 |
Closed |
|
» |
All of the above signals reflect true state of device |
W7 |
Open |
|
|
All of the above signals are forced true |
W7 |
Closed |
|
Note:The above jumpers are mutually exclusive and only one of them should be closed at a time. |
|||
|
PARALLEL PORT CONFIGURATION |
|||||
|
Port |
Address |
IRQ |
W10 |
W14 |
|
|
» |
LPT1 |
378-37Fh |
IRQ7 |
Closed |
Closed |
|
|
Disabled |
N/A |
Disabled |
Open |
Open |
