SOUNDBLASTER AWE64 (CT4381)
|
Card Type |
Sound card |
|
Chip Set |
Creative Technology |
|
I/O Options |
Game/MIDI port, line out, speaker out, microphone in, line in, PC speaker connector, Audio in CD-ROM (2), memory upgrade connector, feature connector |
|
Card Size |
Half-length, full-height card |
|
Data Bus |
16-bit ISA |
|
CONNECTIONS | |||
|
Function |
Label |
Function |
Label |
|
Feature connector |
CN1 |
Line in |
CN7 |
|
Memory upgrade connector |
CN2 |
Microphone in |
CN8 |
|
Audio in CD-ROM |
CN3 |
Line out |
CN9 |
|
Audio in CD-ROM (ATAPI) |
CN4 |
Speaker out |
CN10 |
|
PC speaker connector |
CN5 |
Game/MIDI port |
CN11 |
|
MB PRO connector |
CN6 | ||
|
USER CONFIGURABLE SETTINGS | ||
|
Function |
Label |
Position |
|
MPU-401 enabled |
JP1 |
Closed |
|
MPU-401 disabled |
JP1 |
Open |
| Conectors: CN8 & CN9 - DRAM Upgrade Connectors - Connect an optional memorydaughterboard to increase the memory available to your audio card so that you canexperience and enjoy high quality sound reproduction with SoundFont banks MBPRO - Modem Connector - Conects any modem card that is specificaly designed for this interface MFBEN - enable/disable MPU-401 MIDI Emulation - in MS-DOS and WIN 3.1x Thanks Sara for this Information. |
||
