Dolphin peripherals, llc.

Fastisa-4090

Card Type

Parallel & Serial card

Chip Set

ADP/Startech

Maximum Onboard Memory

None

I/O Options

Parallel ports (3), serial ports (4)

Data Bus

16-bit ISA

Floppy drives supported

None

CONNECTIONS

Function

Location

Function

Location

26-pin parallel port 1

P1

10-pin serial port 2

S2

25-pin parallel port 2

P2

10-pin serial port 3

S3

26-pin parallel port 3

P3

26-pin serial port 4

S4

9-pin serial port 1

S1



USER CONFIGURABLE SETTINGS

Function

Label

Position

»

Printer port P1 is bi-directional mode

JP15

Pins 1 & 2 closed



Printer port P1 is normal mode

JP15

Pins 2 & 3 closed

»

Printer port P2 is bi-directional mode

JP16

Pins 1 & 2 closed



Printer port P2 is normal mode

JP16

Pins 2 & 3 closed

»

Printer port P3 is bi-directional mode

JP17

Pins 1 & 2 closed



Printer port P3 is normal mode

JP17

Pins 2 & 3 closed

SERIAL PORT 1 ADDRESS SELECTION

COM

JP1/pins 1 & 2

JP1/pins 3 & 4

JP1/pins 5 & 6

JP1/pins 7 & 8

»

COM1(3F8h)

Closed

Open

Open

Open



COM2(2F8h)

Open

Closed

Open

Open



COM3(3E8h)

Open

Open

Closed

Open



COM4(2E8h)

Open

Open

Open

Closed

SERIAL PORT 2 ADDRESS SELECTION

COM

JP3/pins 1 & 2

JP3/pins 3 & 4

JP3/pins 5 & 6

JP3/pins 7 & 8



COM1(3F8h)

Closed

Open

Open

Open

»

COM2(2F8h)

Open

Closed

Open

Open



COM3(3E8h)

Open

Open

Closed

Open



COM4(2E8h)

Open

Open

Open

Closed

SERIAL PORT 3 ADDRESS SELECTION

COM

JP5/pins 1 & 2

JP5/pins 3 & 4

JP5/pins 5 & 6

JP5/pins 7 & 8



COM1(3F8h)

Closed

Open

Open

Open



COM2(2F8h)

Open

Closed

Open

Open

»

COM3(3E8h)

Open

Open

Closed

Open



COM4(2E8h)

Open

Open

Open

Closed

SERIAL PORT 4 ADDRESS SELECTION

COM

JP7/pins 1 & 2

JP7/pins 3 & 4

JP7/pins 5 & 6

JP7/pins 7 & 8



COM1(3F8h)

Closed

Open

Open

Open



COM2(2F8h)

Open

Closed

Open

Open



COM3(3E8h)

Open

Open

Closed

Open

»

COM4(2E8h)

Open

Open

Open

Closed

PARALLEL PORT 1 ADDRESS SELECTION

LPT

JP9/pins 1 & 2

JP9/pins 3 & 4

JP9/pins 5 & 6

»

LPT1(3BCh)

Closed

Open

Open



LPT2(378h)

Open

Closed

Open



LPT3(278h)

Open

Open

Closed

PARALLEL PORT 2 ADDRESS SELECTION

LPT

JP11/pins 1 & 2

JP11/pins 3 & 4

JP11/pins 5 & 6



LPT1(3BCh)

Closed

Open

Open

»

LPT2(378h)

Open

Closed

Open



LPT3(278h)

Open

Open

Closed

PARALLEL PORT 3 ADDRESS SELECTION

LPT

JP13/pins 1 & 2

JP13/pins 3 & 4

JP13/pins 5 & 6



LPT1(3BCh)

Closed

Open

Open



LPT2(378h)

Open

Closed

Open

»

LPT3(278h)

Open

Open

Closed

SERIAL PORT 1 INTERRUPT SELECTION

IRQ

JP2/A

JP2/B

JP2/C

JP2/D

JP2/E

JP2/F

JP2/G

JP2/H

JP2/I



IRQ3

Closed

Open

Open

Open

Open

Open

Open

Open

Open

»

IRQ4

Open

Closed

Open

Open

Open

Open

Open

Open

Open



IRQ5

Open

Open

Closed

Open

Open

Open

Open

Open

Open



IRQ7

Open

Open

Open

Closed

Open

Open

Open

Open

Open



IRQ9

Open

Open

Open

Open

Closed

Open

Open

Open

Open



IRQ10

Open

Open

Open

Open

Open

Closed

Open

Open

Open



IRQ11

Open

Open

Open

Open

Open

Open

Closed

Open

Open



IRQ12

Open

Open

Open

Open

Open

Open

Open

Closed

Open



IRQ15

Open

Open

Open

Open

Open

Open

Open

Open

Closed

SERIAL PORT 2 INTERRUPT SELECTION

IRQ

JP4/A

JP4/B

JP4/C

JP4/D

JP4/E

JP4/F

JP4/G

JP4/H

JP4/I

»

IRQ3

Closed

Open

Open

Open

Open

Open

Open

Open

Open



IRQ4

Open

Closed

Open

Open

Open

Open

Open

Open

Open



IRQ5

Open

Open

Closed

Open

Open

Open

Open

Open

Open



IRQ7

Open

Open

Open

Closed

Open

Open

Open

Open

Open



IRQ9

Open

Open

Open

Open

Closed

Open

Open

Open

Open



IRQ10

Open

Open

Open

Open

Open

Closed

Open

Open

Open



IRQ11

Open

Open

Open

Open

Open

Open

Closed

Open

Open



IRQ12

Open

Open

Open

Open

Open

Open

Open

Closed

Open



IRQ15

Open

Open

Open

Open

Open

Open

Open

Open

Closed

SERIAL PORT 3 INTERRUPT SELECTION

IRQ

JP6/A

JP6/B

JP6/C

JP6/D

JP6/E

JP6/F

JP6/G

JP6/H

JP6/I



IRQ3

Closed

Open

Open

Open

Open

Open

Open

Open

Open



IRQ4

Open

Closed

Open

Open

Open

Open

Open

Open

Open



IRQ5

Open

Open

Closed

Open

Open

Open

Open

Open

Open



IRQ7

Open

Open

Open

Closed

Open

Open

Open

Open

Open



IRQ9

Open

Open

Open

Open

Closed

Open

Open

Open

Open

»

IRQ10

Open

Open

Open

Open

Open

Closed

Open

Open

Open



IRQ11

Open

Open

Open

Open

Open

Open

Closed

Open

Open



IRQ12

Open

Open

Open

Open

Open

Open

Open

Closed

Open



IRQ15

Open

Open

Open

Open

Open

Open

Open

Open

Closed

SERIAL PORT 4 INTERRUPT SELECTION

IRQ

JP8/A

JP8/B

JP8/C

JP8/D

JP8/E

JP8/F

JP8/G

JP8/H

JP8/I



IRQ3

Closed

Open

Open

Open

Open

Open

Open

Open

Open



IRQ4

Open

Closed

Open

Open

Open

Open

Open

Open

Open



IRQ5

Open

Open

Closed

Open

Open

Open

Open

Open

Open



IRQ7

Open

Open

Open

Closed

Open

Open

Open

Open

Open



IRQ9

Open

Open

Open

Open

Closed

Open

Open

Open

Open



IRQ10

Open

Open

Open

Open

Open

Closed

Open

Open

Open

»

IRQ11

Open

Open

Open

Open

Open

Open

Closed

Open

Open



IRQ12

Open

Open

Open

Open

Open

Open

Open

Closed

Open



IRQ15

Open

Open

Open

Open

Open

Open

Open

Open

Closed

PARALLEL PORT 1 INTERRUPT SELECTION

IRQ

JP10/A

JP10/B

JP10/C

JP10/D

JP10/E

JP10/F

JP10/G

JP10/H

JP10/I



IRQ3

Closed

Open

Open

Open

Open

Open

Open

Open

Open



IRQ4

Open

Closed

Open

Open

Open

Open

Open

Open

Open



IRQ5

Open

Open

Closed

Open

Open

Open

Open

Open

Open

»

IRQ7

Open

Open

Open

Closed

Open

Open

Open

Open

Open



IRQ9

Open

Open

Open

Open

Closed

Open

Open

Open

Open



IRQ10

Open

Open

Open

Open

Open

Closed

Open

Open

Open



IRQ11

Open

Open

Open

Open

Open

Open

Closed

Open

Open



IRQ12

Open

Open

Open

Open

Open

Open

Open

Closed

Open



IRQ15

Open

Open

Open

Open

Open

Open

Open

Open

Closed

PARALLEL PORT 2 INTERRUPT SELECTION

IRQ

JP12/A

JP12/B

JP12/C

JP12/D

JP12/E

JP12/F

JP12/G

JP12/H

JP12/I



IRQ3

Closed

Open

Open

Open

Open

Open

Open

Open

Open



IRQ4

Open

Closed

Open

Open

Open

Open

Open

Open

Open

»

IRQ5

Open

Open

Closed

Open

Open

Open

Open

Open

Open



IRQ7

Open

Open

Open

Closed

Open

Open

Open

Open

Open



IRQ9

Open

Open

Open

Open

Closed

Open

Open

Open

Open



IRQ10

Open

Open

Open

Open

Open

Closed

Open

Open

Open



IRQ11

Open

Open

Open

Open

Open

Open

Closed

Open

Open



IRQ12

Open

Open

Open

Open

Open

Open

Open

Closed

Open



IRQ15

Open

Open

Open

Open

Open

Open

Open

Open

Closed

PARALLEL PORT 3 INTERRUPT SELECTION

IRQ

JP14/A

JP14/B

JP14/C

JP14/D

JP14/E

JP14/F

JP14/G

JP14/H

JP14/I



IRQ3

Closed

Open

Open

Open

Open

Open

Open

Open

Open



IRQ4

Open

Closed

Open

Open

Open

Open

Open

Open

Open



IRQ5

Open

Open

Closed

Open

Open

Open

Open

Open

Open



IRQ7

Open

Open

Open

Closed

Open

Open

Open

Open

Open



IRQ9

Open

Open

Open

Open

Closed

Open

Open

Open

Open



IRQ10

Open

Open

Open

Open

Open

Closed

Open

Open

Open



IRQ11

Open

Open

Open

Open

Open

Open

Closed

Open

Open



IRQ12

Open

Open

Open

Open

Open

Open

Open

Closed

Open

»

IRQ15

Open

Open

Open

Open

Open

Open

Open

Open

Closed
