DATA TECHNOLOGY CORPORATION

DTC3290ASE

Maximum Onboard Memory

Unidentified

Data Bus

EISA

Card Size

Full height, three-quarters length

Hard Drives Supported

Up to 7 SCSI-2 devices

Floppy Drives Supported

Unidentified

CONNECTIONS

Function

Label

Function

Label

34-pin cable connector - floppy drive

J1

50-pin SCSI connector - internal

J3

50-pin SCSI connector - external

J2

4-pin drive active LED

LED

USER CONFIGURABLE SETTINGS

Setting

Label

Position

»

Factory configured - do not alter

RP1

Unidentified

»

Factory configured - do not alter

RP2

Unidentified

»

Factory configured - do not alter

RP3

Unidentified

»

Factory configured - do not alter

RP4

Unidentified

»

Factory configured - do not alter

RP5

Unidentified

»

Factory configured - do not alter

RP6

Unidentified

»

Factory configured - do not alter

RP7

Unidentified

»

Factory configured - do not alter

RP8

Unidentified

»

Factory configured - do not alter

RP9

Unidentified

»

Factory configured - do not alter

RP10

Unidentified

»

Factory configured - do not alter

RP11

Unidentified

DRAM CONFIGURATION

The configuration of the DRAM on this board is unidentified.

SCSI TERMINATION

The method for selecting SCSI termination is unidentified.
